The NMX-ENC-N2612S supports Dante AV-A, a standard for AVoIP devices created to allow for the interoperability of multiple devices on the network. With Dante AV-A, the NMX-ENC-N2612S is compatible with Dante Controller, Dante Domain Manager, and Dante Director. All signal routing, configuration, and IT-level management for your audio and video devices can now be managed using the same tools.
With the ability to stream video with multiple technologies, the NMX-ENC-N2612S is compatible with a wide variety of decoders. The MWC stream is fully compatible with the NMX-DEC-N2622S Decoder and NMX-DEC-N2625-WP Decoder Wallplate. The H.26x stream generated by the NMX-ENC-N2612S can be configured to work with N3000 series decoders and the NMX-WP-N3510 Windowing Processor, N3300 series decoders, or 3rd-party devices and streaming services.
| Video Inputs | (2) HDMI |
| Video Outputs | Network video over Ethernet via RJ45 port, HDMI Loop-Out |
| Video Resolution Support | Supports most common resolutions up to 4096 x 2160 - Reference the user manual for specific resolution support. |
| Audio Inputs | Embedded audio on HDMI or Analog Stereo (Balanced) |
| Audio Outputs | Network PCM or Dante audio over Ethernet via RJ45, HDMI Loop-Out |
| Ports | +12V 2A DC power input, (P0) Gigabit Ethernet port with PoE+ support, (P1) Gigabit Ethernet port, (IR) 2-pin 3.5mm screw terminal, (RS232) 3-pin 3.5mm screw terminal, (Audio) 5-pin 3.5mm screw terminal, HDMI video loop-out, (2) HDMI video input, USB Micro B Host port (front panel), (IR IN) 3-pin 3.5mm screw terminal (front panel) |
| Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 90% RH (non-condensing) |
| Heat Dissipation | Up to ~85 BTU/hr |
| Dimensions (H x W x D) | 1 1/6" x 7 7/8" x 5" (26.6mm x 200mm x 127mm) |
| Product Weight | 2.16 lbs. (Approx. 0.98kg) |
